HMI 1200W/DXS 10/CS 1/SKU
Product features and benefits
- High intensity light providing true color performance with a >90
- Longer life with heat dissipating round moly-foil design on lamps ≥ 6000W
- Mechanically robust with eXtreme Seal (XS) technology, up to 450°C at the pinch seal
- Capable of hot restrike ignition
- High stability of color temperature over lifetime
- High energy efficiency providing up to 100 lm/W
- Compression sealed base provides ehanced durability
Areas of application
- Studio, TV, & Film
- Professional & High Speed Photography
- Solar Simulation
Safety advice
Because of their high luminance, UV radiation and high internal pressure during operation, HMI lamps may only be operated in enclosed lamp casings specially constructed for the purpose. Appropriate filters must ensure that UV radiation is reduced to an acceptable level. Mercury is released if the lamp breaks. Special safety precautions must be taken. Information on safety and handling is available on request or can be found in the leaflet included with the lamp or in the operating instructions.
Because of their high luminance, UV radiation and high internal pressure during operation, HMI lamps may only be operated in enclosed lamp casings specially constructed for the purpose. Appropriate filters must ensure that UV radiation is reduced to an acceptable level. Mercury is released if the lamp breaks. Special safety precautions must be taken. Information on safety and handling is available on request or can be found in the leaflet included with the lamp or in the operating instructions.
Technical Data
General Product Information
Global order reference
HMI 1200 W/DXS
Product number (Americas)
55139
Product name (Americas)
HMI 1200W/DXS 10/CS 1/SKU
Family brand
HMI
Global order reference
HMI 1200 W/DXS
Electrical Data
Nominal wattage
1200 W
Nominal voltage
100 V
Nominal current
13.8 A
Type of current
AC
Photometric Data
Nominal luminous flux
110000 lm
Color temperature
6000 K
Color rendering index Ra
> 90
Physical Attributes & Dimensions
Lamp base
SFc15.5
Diameter (in)
1.063 in
Diameter
27.0 mm
Length
220.0 mm
Length with base excl. base pins/connection
180.00 mm
Product weight
104.00 g
Operating Conditions
Burning position
Any
Lifetime Data
Nominal lifetime
1000 hr
Environmental & Regulatory Information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Primary article identifier
4008321931153
Declaration no. in SCIP database
No declarable substances contained
Candidate list substance 1
No declarable substances contained
Packaging information
Product number |
EAN/UPC |
Packaging |
Quantity |
Outside dimensions l x w x h |
Gross weight |
|---|---|---|---|---|---|
| 55139 | 4008321931153 | SHIPPING BOX | 1 | 12.0in x 3.2in x 4.5in | 0.6lb |
